220V 230V 240V Eaton Ellipse Eco 800 USB IEC UPS Uninterruptible Power Supply
| Place of Origin | China |
|---|---|
| Brand Name | Eaton |
| Certification | CE |
| Model Number | Eaton Ellipse Eco |
| Packaging Details | cartons |
| Delivery Time | 30days |
| Payment Terms | T/T, Western Union, MoneyGram |
| Supply Ability | 1000pcs/months |
Contact me for free samples and coupons.
WhatsAPP:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Eaton Ellipse Eco 800 USB IEC | Power Level | 500-1600VA |
|---|---|---|---|
| Technology | Offline | Product Type | Offline UPS |
| Number Of Sockets | 4 Or 8 | Rated Frequency | 50-60 Hz |
| Voltage Range | 184 V - 264 V | Input Voltage | 184 V - 264 V |
| Output Voltage | 220 V / 230 V / 240 V | Input Protection | Resettable Circuit Breaker |
| EcoControl Function | 20%-25% | Battery Type | Replaceable Sealed Lead-acid Battery |
| Deep Discharge Protection | 4 Hours | Communication Port | USB |
| Safety Standard | IEC 62040-1，IEC 60950-1，IEC 62040-2，CB，CE | Surge Protection | IEC 61643-1 |
| Highlight | UPS Eaton Ellipse Eco 800 USB,Eaton Ellipse Eco 800 USB IEC,IEC UPS Uninterruptible Power Supply |
||
You can tick the products you need and communicate with us in the message board.
| Model | Power | |
|---|---|---|
| EL650USBIEC | 650VA/400W | |
| EL800USBIEC | 800VA/500W | |
| EL1200USBIEC | 1200VA/750W | |
| EL1600USBIEC | 1600VA/1000W |
Product Description
Eaton Ellipse ECO 800 USB IEC UPS
Eaton Ellipse ECO UPS USB IEC, 800 VA, 500 W, Input: C14, Outputs: (3) C13, (1) C13 surge only, Tower/rack, Standby
As well as providing a power supply backed up by a battery to keep equipment operating during a power failure, the Ellipse Eco also provides effective protection against damaging surges. The Eco Control function automatically disables peripherals when the master device is turned off in order to save up 25 % more energy compared to previous generation of UPS. This unit can either be placed horizontally, 19 inch rack mounted or wall mounted. The Ellipse Eco also includes the Eaton Intelligent Power Manager software. It is an ideal protection for all business computers.
Key Features
- Eco Control function helps you save up to 25% energy compared to previous generation UPSs (USB models)
- Includes a high performance surge-protection device which complies with IEC 61643-1 standard
- Up to 8 outlets to connect your PC & peripherals
- Convenient extra-flat design for easy installation in any office environment
- USB port & Power Management software for Windows 7, Vista, XP, Linux and Mac OS (USB models)
- Protects data connections such as Ethernet, internet and telephone lines
Energy-efficient power protection for business computers
With an efficient electrical design and the EcoControl function, which automatically disables peripherals when the master device is turned off, the Eaton Ellipse ECO helps you make energy savings of up to 25 percent compared to previous-generation UPSs. As well as providing a power supply backed up by a battery to keep equipment operating during a power failure, the Ellipse ECO also provides effective protection against damaging surges.
Easy integration and installation
The Ellipse ECO's extra-flat design makes it easy to install in any office environment: installation options include vertical box format, below the desk, horizontally under a monitor and 19" rack-mounted.
Complete peace of mind
Periodic battery self-test ensures early detection of a battery that needs to be replaced. Easy-to-replace battery helps to extend UPS service life. Push-button circuit breaker enables easy recovery from an overload or short circuit.
ECOCONTROL FUNCTION
Automatically disables peripherals when the master device is turned off, the Eaton Ellipse ECO helps you make energy savings of up to 25 per cent compared to previous-generation UPSs.
EXTRA-FLAT
The Ellipse ECO’s extra-flat design makes it easy to install in any office environment: installation options include verticalbox format, below the desk, horizontally under a monitor, 19” rack-mounted (optional 2U kit) and wall-mounted (optional kit).
| Specification | 500 | 650 | 650 USB | 800 USB | 1200 USB | 1600 USB |
| Rated power (VA/W) | 500VA / 300W | 650VA / 400W | 650VA / 400W | 800VA / 500W | 1200VA / 750W | 1600VA / 1000W |
| Application | ||||||
| Sockets Number | 4 | 4 | 4 | 4 | 8 | 8 |
| Characteristic | ||||||
| Nominal input voltage | 230 V | |||||
| Input voltage | 184V - 264V (adjustable to 161V - 284V) | |||||
| Output voltage | 230V (adjustable to 220V, 230V, 240V) | |||||
| Frequency | 50-60Hz automatic selection | |||||
| Input protection | Resettable circuit breaker | |||||
| Characteristic | ||||||
| Energy-saving design | Yes | Yes | Yes | Yes | Yes | Yes |
| EcoControl function | - | - | 20% | 20% | 25% | 25% |
| Surge protection | ||||||
| Battery | ||||||
| Battery type | Replaceable sealed lead-acid battery | |||||
| Automatic battery test | Yes | Yes | Yes | Yes | Yes | Yes |
| Cold start | Yes | Yes | Yes | Yes | Yes | Yes |
| Deep discharge protection | 4hours | 4hours | 4hours | 4hours | 4hours | 4hours |
| Battery replacement indicator | LED+ Audible Alarm | |||||
| Battery operating time at 50% load | 9mins | 9mins | 9mins | 11mins | 10mins | 11mins |
| Battery operating time at 70% load | 5mins | 6mins | 6mins | 6mins | 6mins | 6mins |
| Communication | ||||||
| Communication port | - | - | USB interface | USB interface | USB interface | USB interface |
| Software | Comes standard with Eaton smart power software (compatible with: Windows, Mac OS X, Linux) | |||||
| Line protection | Telephone / Fax / Modem / Internet and Ethernet | |||||
| Standard | ||||||
| Security/EMC | IEC 62040-1, IEC 60950-1, IEC 62040-2, CB, CE | |||||
| Surge protection | IEC 61643-1 | |||||
| Size and weight | ||||||
| Size(mm) | 263 x 81 x 235 | 263 x 81 x 235 | 263 x 81 x 235 | 263 x 81 x 235 | 305 x 81 x 312 | 305 x 81 x 312 |
| Weight(kg) | 2.9 kg | 3.6 kg | 3.6 kg | 4.1 kg | 6.7 kg | 7.8 kg |
