Home > Products >

Eaton UPS

>

15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX

Quality 15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX factory
Quality 15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX factory
Quality 15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX factory
Quality 15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX factory
Quality 15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX factory
Quality 15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX factory
Quality 15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX factory

15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX

Product Summary

Product nameEaton 9PX MarinePower level1.5KVA-3KVAForm FactorRack/TowerTechnologyOnline UPSRated frequency40-70 HzInput Voltage200/208/220/230/240VOutput Voltage200/208/220/230/240VEfficiency98%Short circuit current90A/120AOverload capacity102-110% : 120s, 110-125%: 60s, 125-150%: 10s, >150%: ...

Key Attributes
Brand Name: Eaton
Model Number: Eaton 9PX Marine
Place of Origin: Guangdong, China
Price: $3,366.00 - $3,696.00/pieces
Product Custom Attributes
Highlight

15KVA marine UPS power supply

,

30KVA Eaton 9PX UPS

,

on-line UPS for networking

Warranty:
1year
Phase:
Single Phase
Protection:
Short Circuit
Type:
On-line
Application:
Networking
Product Name:
Eaton 9PX Marine
Power Level:
1.5KVA-3KVA
Form Factor:
Rack/Tower
Technology:
Online UPS
Rated Frequency:
40-70 Hz
Input Voltage:
200/208/220/230/240V
Output Voltage:
200/208/220/230/240V
Efficiency:
98%
Short Circuit Current:
90A/120A
Overload Capacity:
102-110% : 120s, 110-125%: 60s, 125-150%: 10s, >150%: 900ms
Product Description
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 0
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 1
Product name
Eaton 9PX Marine
Power level
1.5KVA-3KVA
Form Factor
Rack/Tower
Technology
Online UPS
Rated frequency
40-70 Hz
Input Voltage
200/208/220/230/240V
Output Voltage
200/208/220/230/240V
Efficiency
98%
Short circuit current
90A/120A
Overload capacity
102-110% : 120s, 110-125%: 60s, 125-150%: 10s, >150%: 900ms
Battery management
ABM® and temperature compensated charging method (user selectable), automatic battery test, deep discharge protection
Communication Ports
1 USB port + 1 RS232 serial port and relay contacts
Communication Slot
1 slot for Network-MS board (standard in Netpack version), ModBus-MS or Relay-MS board.
Operating temeprature
0 ~ 40°C
Noise level
<50db
Safety
IEC/EN 62040-1, UL 1778（1:1）
EMC, Performance
IEC/EN 62040 -2, FCC Class A（1:1），IEC/EN 62040-3
Approvals
CE，CB（TUV），UL（1:1）
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 2
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 3
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 4
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 5
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 6
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 7
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 8
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 9
COMPANY PROFILE:
Vesion Tech Co., Ltd. is located in Futong Haizhi Technology Park, Shenzhen, with a 1,500 m² R&D center and sales center base. Also，our business partner have an automated production plant of 10,000 m² in Foshan, Guangdong.
We are a high-tech company focusing on one-stop data centers, PV new energy, and smart power supply and distribution. We provide users with infrastructure products such as UPS system, HVAC, MDC, smart power supplies, and PV new energy.
As a technical facilities provider, Vesion also cooperates with well-known brands such as Eaton, Vertiv, Santak, APC, etc. to provide customers with the best choice.
Vesion follows the national carbon neutrality strategy and based on the development concept of independent innovation, constantly pursues leadership in energy-saving technology and innovation in production processes, and has established a complete R&D and quality assurance system. Provide customers with data center infrastructure and photovoltaic new energy solutions.

15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 10
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 11
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 12
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 13
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 14
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 15
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 16
15KVA 30KVA On-line 200/208/220/230/240V Marine Power Supply UPS For Networking Eaton 9PX 17
1. May I take some samples to test before I placing the order?
Yes, we can offer sample testing for you to verify product quality and performance.

2. What is the warranty?
We support 1 years warranty.

3.What can you buy from us?
Eaton, Vertiv, APC, Santak, Vesion & OEM/ODM UPS; Cooling, MDC, PDU and so on.

4. What payment methods does your conmpany support?
We could accept T/T, credit card, Alipay or L/C at sight.

5. What are the terms can you offer for us?
We could offer EXW, FOB, CIF, DDP and so on.
