5000m3/h Visench CRA 12.5KW Server Room Precision Air Conditioner for Lab Data Center
CRA series room-level precision air conditioner technical parameters and configuration table (row level)Air conditioner typeSingle cooling typeConstant temperature and humidity typeIndoor unit modelCRA025HAIT00CRA025HAITNNCRA040HAITNNOutdoor unit modelECA033ECA033ECA033Energy efficiency ratio2.82.83...
12.5KW precision air conditioner
,server room air conditioner 5000m3/h
,data center air conditioner with warranty
CRA series room-level precision air conditioner technical parameters and configuration table (row level) | ||||||||
Air conditioner type | Single cooling type | Constant temperature and humidity type | ||||||
Indoor unit model | CRA025HAIT00 | CRA025HAITNN | CRA040HAITNN | |||||
Outdoor unit model | ECA033 | ECA033 | ECA033 | |||||
Energy efficiency ratio | 2.8 | 2.8 | 3.02 | |||||
Power Specifications | 380VAC/50HZ | |||||||
Maximum current | 20A | 23.6A | 40A | |||||
Recommended input space | 32A/4P | 40A/4P | 64A/4P | |||||
Cooling capacity (kw） | 25 | 25 | 40.3 | |||||
Sensible cooling capacity (kw） | 25 | 25 | 40.3 | |||||
sensible heat ratio | 1 | 1 | 1 | |||||
Air volume (m³/h） | 5000 | 5000 | 9000 | |||||
Return air volume (m³/h） | 5000 | 5000 | 9000 | |||||
heat exchange capacity(kw) | 27 | 27 | 45 | |||||
PTC Electric heating power (kw） | / | 3 | 6 | |||||
Electrode humidification amount (kg/h) | / | 3 | 3 | |||||
compressor | Number of presses | 1 | ||||||
Fixed （frequency） conversion | DC frequency conversion | |||||||
Compressor type | Rotor compressor | Rotor compressor | scroll compressor | |||||
indoor fan | Number of fans | 6 | 6 | 2 | ||||
Fan form | ECCentrifugal fan | 3 | 2 | |||||
outdoor fan | Number of fans | 3 | 3 | 2 | ||||
Fan form | Axial Fan | |||||||
Evaporator form | Large area "/" type evaporator | |||||||
Expansion valve | type | Electronic expansion valve | ||||||
Filter | filter level | Medium and high efficiency:G4class | ||||||
refrigerant | type | R410A | ||||||
Indoor unit factory precharge (kg) | No precharge at the factory | |||||||
Factory precharge of outdoor unit (kg) | No precharge at the factory | |||||||
Noise value(dB) | Indoor unit | 74 | 74 | 76 | ||||
The outdoor unit | 64 | 64 | 65.5 | |||||
Dimensions(mm) | Indoor unit (w*d*h) | 300*1200*2000 | 300*1200*2000 | 600*1200*2000 | ||||
Outdoor unit (w*d*h) | 1845*400*985 | 1845*400*985 | 2245*400*1135 | |||||
weight(kg) | Indoor unit | 190 | 190 | 260 | ||||
The outdoor unit | 115 | 115 | 160 | |||||
We are based in Guangdong, China, start from 2015,sell to Mid East(23.00%),Southeast Asia(21.00%),South America(20.00%),Africa(10.00%),Oceania(6.00%),South Asia(5.00%),North America(5.00%),Eastern Asia(2.00%),Western Europe(2.00%),Central America(2.00%),Northern Europe(2.00%),Southern Europe(1.00%),Eastern Europe(1.00%). There are total about 101-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
UPS, Lithium Battery, Lead Acid Battery, Room Cooling, PDU
4. why should you buy from us not from other suppliers?
Vesion is a global group company. Headquartered in Taipei, Vesion was founded in the 1980s. It has a history of producing industrial batteries and uninterruptible power supplies for more than 30 years. It has invested and built factories in Vietnam
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian
-
