Visench CRA Series 12.5KW 25KW 40KW 50KW 60KW Room-Level Precision Air Conditioner
CRA series room-level precision air conditioner technical parameters and configuration table (row level)Air conditioner typeSingle cooling typeConstant temperature and humidity typeIndoor unit modelCRA025HAIT00CRA025HAITNNCRA040HAITNNOutdoor unit modelECA033ECA033ECA033Energy efficiency ratio2.82.83...
Visench CRA precision air conditioner
,12.5KW room-level cooling unit
,60KW industrial precision AC
CRA series room-level precision air conditioner technical parameters and configuration table (row level) | ||||||||
Air conditioner type | Single cooling type | Constant temperature and humidity type | ||||||
Indoor unit model | CRA025HAIT00 | CRA025HAITNN | CRA040HAITNN | |||||
Outdoor unit model | ECA033 | ECA033 | ECA033 | |||||
Energy efficiency ratio | 2.8 | 2.8 | 3.02 | |||||
Power Specifications | 380VAC/50HZ | |||||||
Maximum current | 20A | 23.6A | 40A | |||||
Recommended input space | 32A/4P | 40A/4P | 64A/4P | |||||
Cooling capacity (kw） | 25 | 25 | 40.3 | |||||
Sensible cooling capacity (kw） | 25 | 25 | 40.3 | |||||
sensible heat ratio | 1 | 1 | 1 | |||||
Air volume (m³/h） | 5000 | 5000 | 9000 | |||||
Return air volume (m³/h） | 5000 | 5000 | 9000 | |||||
heat exchange capacity(kw) | 27 | 27 | 45 | |||||
PTC Electric heating power (kw） | / | 3 | 6 | |||||
Electrode humidification amount (kg/h) | / | 3 | 3 | |||||
compressor | Number of presses | 1 | ||||||
Fixed （frequency） conversion | DC frequency conversion | |||||||
Compressor type | Rotor compressor | Rotor compressor | scroll compressor | |||||
indoor fan | Number of fans | 6 | 6 | 2 | ||||
Fan form | ECCentrifugal fan | 3 | 2 | |||||
outdoor fan | Number of fans | 3 | 3 | 2 | ||||
Fan form | Axial Fan | |||||||
Evaporator form | Large area "/" type evaporator | |||||||
Expansion valve | type | Electronic expansion valve | ||||||
Filter | filter level | Medium and high efficiency:G4class | ||||||
refrigerant | type | R410A | ||||||
Indoor unit factory precharge (kg) | No precharge at the factory | |||||||
Factory precharge of outdoor unit (kg) | No precharge at the factory | |||||||
Noise value(dB) | Indoor unit | 74 | 74 | 76 | ||||
The outdoor unit | 64 | 64 | 65.5 | |||||
Dimensions(mm) | Indoor unit (w*d*h) | 300*1200*2000 | 300*1200*2000 | 600*1200*2000 | ||||
Outdoor unit (w*d*h) | 1845*400*985 | 1845*400*985 | 2245*400*1135 | |||||
weight(kg) | Indoor unit | 190 | 190 | 260 | ||||
The outdoor unit | 115 | 115 | 160 | |||||
