Santak UPS

>

Santak ARRAY 3A3 PT 200kVA Frequency Online Backup Supply UPS with 25kW Power Module

Quality Santak ARRAY 3A3 PT 200kVA Frequency Online Backup Supply UPS with 25kW Power Module factory
Quality Santak ARRAY 3A3 PT 200kVA Frequency Online Backup Supply UPS with 25kW Power Module factory
Quality Santak ARRAY 3A3 PT 200kVA Frequency Online Backup Supply UPS with 25kW Power Module factory
Quality Santak ARRAY 3A3 PT 200kVA Frequency Online Backup Supply UPS with 25kW Power Module factory
Quality Santak ARRAY 3A3 PT 200kVA Frequency Online Backup Supply UPS with 25kW Power Module factory
Quality Santak ARRAY 3A3 PT 200kVA Frequency Online Backup Supply UPS with 25kW Power Module factory

Santak ARRAY 3A3 PT 200kVA Frequency Online Backup Supply UPS with 25kW Power Module

Product Summary

Product nameARRAY 3A3 PT Series（25kVA～200kVA)Power Module25kWPower Factor0.99Input Voltage380Vac/220VacInput Frequency50/60HzOutput Voltage380Vac/220VacOutput Frequency50/60HzOverload Capacity125%:10min 150%:1minInverter/Rectifier TopologyThree level, high-frequency PWM IGBT modulation technologyBat...

Key Attributes
Brand Name: SANTAK
Model Number: Santak ARRAY 3A3 PT UPS
Place of Origin: China
Price: $1,992.00 - $8,924.00/units
Product Custom Attributes
Highlight

Santak UPS 200kVA online backup

,

Santak UPS 25kW power module

,

frequency online UPS with warranty

Warranty:
2 YEARS
Phase:
Three Phase
Protection:
Short Circuit
Type:
On-line
Application:
Networking
Product Name:
ARRAY 3A3 PT Series(25kVA~200kVA)
Power Module:
25kW
Power Factor:
0.99
Input Voltage:
380Vac/220Vac
Input Frequency:
50/60Hz
Output Voltage:
380Vac/220Vac
Output Frequency:
50/60Hz
Overload Capacity:
125%:10min 150%:1min
Battery Type:
Lead-acid Battery, Lithium Battery
Battery Voltage:
432~504Vdc
Product Description
Product nameARRAY 3A3 PT Series（25kVA～200kVA)Power Module25kWPower Factor0.99Input Voltage380Vac/220VacInput Frequency50/60HzOutput Voltage380Vac/220VacOutput Frequency50/60HzOverload Capacity125%:10min 150%:1minInverter/Rectifier TopologyThree level, high-frequency PWM IGBT modulation technologyBattery TypeLead-acid battery, lithium batteryBattery Voltage432~504Vdc Visense is a global group company. Headquartered in Taipei, visense was founded in the 1980s. It has a history of producing industrial batteries and uninterruptible power supplies for more than 30 years. It has invested and built factories in Vietnam, Shenzhen, Zhongshan, Henan and Hunan, China, specializing in the production of valve controlled lead acid sealed batteries and uninterruptible power supplies. It has become one of the most powerful suppliers of backup power supplies in the world. As a subsidiary of Weishen Technology Co., Ltd., Shenzhen Weishen Power Technology Co., Ltd. has advanced technology in the production and design of spare power types of valve regulated maintenance free lead-acid batteries (superfine glass fiber separator and colloidal battery), such as communication type, UPS type and other application types (such as emergency and circulation). 1. Who are we?We are based in Guangdong, China, start from 2015,sell to Mid East(23.00%),Southeast Asia(21.00%),South America(20.00%),Africa(10.00%),Oceania(6.00%),South Asia(5.00%),North America(5.00%),Eastern Asia(2.00%),Western Europe(2.00%),Central America(2.00%),Northern Europe(2.00%),Southern Europe(1.00%),Eastern Europe(1.00%),Domestic Market(0.00%). There are total about 11-50 people in our office.2. How can we guarantee quality?Always a pre-production sample before mass production;Always final Inspection before shipment;3.What can you buy from us?Mini UPS, Offline UPS, Online UPS, Portable Power Supply, Inverter4. Why should you buy from us not from other suppliers?Visense is a global group company. Headquartered in Taipei, visense was founded in the 1980s. It has a history of producing industrial batteries and uninterruptible power supplies for more than 30 years. It has invested and built factories in Vietnam, Shen5. What services can we provide?Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian

🔹 480VAC Configuration Available: This UPS system supports 380/400/415/480VAC three-phase input and output, making it suitable for global power distribution standards including North American 480VAC grids.

🔹 UL Listed Certified: UL Listed UPS certified for compliance with international safety and performance standards, ensuring reliable operation in mission-critical applications worldwide.
