Static Transfer Switch STS

>

Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch

Quality Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch factory
Quality Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch factory
Quality Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch factory
Quality Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch factory
Quality Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch factory
Quality Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch factory

Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch

Product Summary

Technical specificationsRated currentSTS 63A/3PSTS 100A/3PSTS 250A/3PSTS 400A/3PSTS 630A/3P1000A/3PInput metricsSourceTwo input sourcesInput method 3φ+N+PERated frequency50Hz/60HzOutput indicatorsPower factor0.75～1.0 leading or laggingOverload capacity125% 30Min，150%2MinSwitching methodBreak-Before...

Key Attributes
Brand Name: Vertiv
Model Number: STS 200A, STS 200A
Place of Origin: Guangdong, China
MOQ: 5 pieces
Price: $17,063.00/pieces >=5 pieces
Product Custom Attributes
Highlight

IP11 Static Transfer Switch

,

3PSTS Static Transfer Switch

,

Max. Current 200A STS

Number Of Pole:
3
Rated Current:
16A
Frame Current:
1
Max. Current:
STS 200A
IP Level:
IP11
Color:
White
Product Name:
STS AC220V Sts Single-phase STS Static Transfer Switch
Type:
High Voltage
Material:
Copper
Rated Current:
STS 63A-1000A
Rated Voltage:
AC 220V
Application:
Industrial
Product Description
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 0
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 1
Technical specifications
Rated current
STS 63A/3P
STS 100A/3P
STS 250A/3P
STS 400A/3P
STS 630A/3P
1000A/3P
Input metrics
Source
Two input sources
Input method
 3φ+N+PE
Rated frequency
50Hz/60Hz
Output indicators
Power factor
0.75～1.0 leading or lagging
Overload capacity
125% 30Min，150%2Min
Switching method
Break-Before-Make
Intermittent time
<5ms，Typical value:3ms
Structural specifications
Width(mm)
600
600
800
800
800
2117
Depth(mm)
800
800
800
800
800
800
Height(mm)
1900
1900
1900
1900
1900
2000
Weight(Kg)
205
205
300
300
470
1100
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 2
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 3
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 4
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 5
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 6
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 7
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 8
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 9
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 10
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 11
COMPANY PROFILE:
Vesion Tech Co., Ltd. is located in Futong Haizhi Technology Park, Shenzhen, with a 1,500 m² R&D center and sales center base. Also，our business partner have an automated production plant of 10,000 m² in Foshan, Guangdong.
We are a high-tech company focusing on one-stop data centers, PV new energy, and smart power supply and distribution. We provide users with infrastructure products such as UPS system, HVAC, MDC, smart power supplies, and PV new energy.
As a technical facilities provider, Vesion also cooperates with well-known brands such as Eaton, Vertiv, Santak, APC, etc. to provide customers with the best choice.
Vesion follows the national carbon neutrality strategy and based on the development concept of independent innovation, constantly pursues leadership in energy-saving technology and innovation in production processes, and has established a complete R&D and quality assurance system. Provide customers with data center infrastructure and photovoltaic new energy solutions.

Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 12
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 13
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 14
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 15
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 16
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 17
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 18
Max. Current 200A STS 3PSTS 64A 100A 200A 300A 400A 630A IP11 Static Transfer Switch 19
1. May I take some samples to test before I placing the order?
Yes, we can offer sample testing for you to verify product quality and performance.

2. What is the warranty?
We support 1 years warranty.

3.What can you buy from us?
Eaton, Vertiv, APC, Santak, Vesion & OEM/ODM UPS; Cooling, MDC, PDU and so on.

4. What payment methods does your conmpany support?
We could accept T/T, credit card, Alipay or L/C at sight.

5. What are the terms can you offer for us?
We could offer EXW, FOB, CIF, DDP and so on.
