Home > Products >

Vertiv UPS

>

20kVA Vertiv GXT5 UPS Online Double Conversion UPS GXT5-20KIRT9UXLE

Quality 20kVA Vertiv GXT5 UPS Online Double Conversion UPS GXT5-20KIRT9UXLE factory
Quality 20kVA Vertiv GXT5 UPS Online Double Conversion UPS GXT5-20KIRT9UXLE factory
Quality 20kVA Vertiv GXT5 UPS Online Double Conversion UPS GXT5-20KIRT9UXLE factory
Quality 20kVA Vertiv GXT5 UPS Online Double Conversion UPS GXT5-20KIRT9UXLE factory

20kVA Vertiv GXT5 UPS Online Double Conversion UPS GXT5-20KIRT9UXLE

Product Summary

Vertiv GXT5 UPS 20kVA Online Double Conversion Rack Online UPS GXT5-20KIRT9UXLE Vertiv Liebert GXT5 Liebert GXT5 from Vertiv is an online double-conversion UPS series that provides high power outage protection and continuous power conditioning in a rack or tower configuration that is compact and ...

Key Attributes
Brand Name: Vertiv
Model Number: Vertiv GXT5 UPS
Place of Origin: China
Certification: CE
Supply Ability: 1000pcs/months
Delivery Time: 60days
Payment Terms: T/T, Western Union, MoneyGram
Standard Packaging: cartons
Product Custom Attributes
Highlight

20kVA Online Double Conversion UPS

,

Vertiv GXT5 UPS

,

GXT5-20KIRT9UXLE

Product Name:
Vertiv GXT5 UPS
Power Level:
5KVA - 20KVA
Technology:
230 VAC
Product Type:
Tower UPS/Rack-mounted UPS
Input Voltage:
230 VAC
Rated Frequency:
50 Hz / 60 Hz
Frequency Range:
40-70Hz; Auto Sensing
Output Voltage:
200/208/220/230/240 VAC
Rated Frequency:
50-60Hz
Waveform:
Sine Wave
Battery Type:
Valve-regulated,non-spillable, Lead Acid
Rated Voltage:
36 Vdc, 48 Vdc, 72 Vdc
Charger Current:
Nominal 2.2 A; Maximum 8 A
Operating Temperature:
Full Power Up To 40 ºC (up To 50 ºC With Derating)
Storage Temperature, °C:
- 15 To + 40
Relative Humidity:
0 To 95% Non-condensing
Operating Elevation:
Up To 3,000 M At 25°C Without Derating
Audible Noise:
55dB
Safety:
UL-1788, IEC62040-1:2008 Version, GS Mark
Emissions:
IEC/EN/AS 62040-2 2nd Ed (Cat 2)
Transportation:
ISTA Procedure 1E
Product Description

Vertiv GXT5 UPS 20kVA Online Double Conversion Rack Online UPS GXT5-20KIRT9UXLE





Vertiv Liebert GXT5

Liebert GXT5 from Vertiv is an online double-conversion UPS series that provides high power outage protection and continuous power conditioning in a rack or tower configuration that is compact and versatile. The high power efficiency of the Vertiv Liebert GXT5 single-phase UPS makes it ideal for protecting critical infrastructure in both centrally managed and Edge network applications. When extended, uninterrupted power is required, scalable runtime options with corresponding external battery cabinets provide added flexibility. In addition, the Liebert GXT5 gives the battery health status and an estimated replacement date for intelligent battery health management.



Benefits



• Designed for high availability

• User friendly operation and installation

• Longer life time and run-time of the batteries

• Optimized energy and capacity management

• Seamless connectivity





Features



• Capability for parallel/redundant operation (10kVA)

• Integrated batteries and easy to install, configure and operate

• New RDU101 SNMP/webcard with advanced features

• Compatibility with environmental sensors

• Integrated dry-contacts and configurable definition

• DCIM compatible: Power Insight

• Energy Star® 2.0 certified

• Programmable output sockets for optimum battery usage





Specifications for GXT5-20KIRT9UXLE

Battery

Battery capacity

9 Ah

Battery technology

Sealed Lead Acid (VRLA)

Battery voltage

12 V

Hot-swap battery

Yes

Number of batteries supported

32

Typical backup time at full load

2.5 min

Design

Certification

IEC/EN/AS 62040-2 2nd Ed (Cat 2 – 6); FCC 15 A CISPR22 A(RFI) CE

Display

LCD

Display type

LCD

Energy Star certified

Yes

Form factor

Rackmount/Tower

International Protection (IP) code

IP20

Product colour

Black

RoHS compliance

Yes

Safety

CE

Features

Audible alarm(s)

Yes

Efficiency

95 %

Emergency Power Off (EPO)

Yes

Input frequency

50/60 Hz

Input operation voltage (max)

288 V

Input operation voltage (min)

176 V

Noise level

58 dB

Number of input phases

1

Number of output phases

1

Output frequency

50/60 Hz

Output operation voltage (max)

240 V

Output power

20000 Watt

Output power capacity

20 kVA

Output power factor

1

Output voltage regulation

3 %

Power factor

1

Power protection features

Overload

UPS topology

Double-conversion (Online)

Waveform

Sine

Logistics data

Harmonized System (HS) code

85078000

Operational conditions

Operating altitude

0 - 3000 m

Operating relative humidity (H-H)

0 - 95 %

Operating temperature (T-T)

0 - 40 °C

Storage temperature (T-T)

-15 - 40 °C

Other features

Battery type

VRLA

Bypass

Yes

Input connection type

Hardwire (common or split bypass)

Nominal input voltage

200-240 V

Nominal output voltage

230 V

Output connections

Terminal Blocks

Overload protection

Yes

Package dimensions

Depth (package,cm)

39.4 cm

Gross Weight (Package, kg)

186.7 kg

Height (package,cm)

63 cm

Width (package,cm)

43 cm

Ports & interfaces

AC outlet types

C13 coupler, C19 coupler

AC outlets quantity

6 AC outlet(s)

Serial interface type

RS-232, RS-485

Serial ports quantity

1

USB port

Yes

Product dimensions

Net Weight (Product, kg)

135.5 kg

Product Depth

63 cm

Product Height

39.4 cm

Product Width

43 cm

Technical details

Harmonized System (HS) code

85078000

Sustainability certificates

RoHS, ENERGY STAR

Vendor information

Brand Name

Vertiv

Warranty

2 Year(s)
